The Circutor EC96 20A (code M10235) is a panel-mount moving iron ammeter for alternating current applications, providing a clear visual readout of current up to 20 A. Housed in a 96 x 96 mm DIN panel format, it delivers true RMS measurement with class 1.5 accuracy and requires no auxiliary power supply for operation.

Technical specifications:

• Model: EC96 20A
• Circutor code: M10235
• EAN: 8433059001254
• Instrument type: Moving iron ammeter
• Measurement range: 20 A
• Measurement: True RMS
• Accuracy class: 1.5 (1.5% FE)
• Scale: 90, P2
• Panel module size: 96 x 96 mm
• Overall dimensions: 96 x 96 x 49.2 mm
• Mounting: Panel
• Weight: 0.22 kg
• Front protection: IP 52
• Terminal protection: IP 00
• Power consumption: 0.3 to 1.5 VA
• Frequency range: 20 to 100 Hz
• Allowable overload: 1.2 In continuous; 5 In for 30 s; 10 In for 5 s; 40 In for 1 s
• Insulation voltage: 2 kV at 50 Hz (less than 1 min)
• Working temperature: +10 to +30 C
• Storage temperature: -25 to +40 C
• Standards: CE, BS 89, UNE-EN 60051, IEC 144, DIN 43780, IEC 51, UNE 21318

Features and benefits:

• No auxiliary power supply required – the instrument draws operating power directly from the measured circuit, reducing wiring complexity and installation time.
• Scales are interchangeable across the EC48, EC72, EC96, EM 45, EC 72 FA, and EC 96 FA series, allowing a single replacement scale to serve multiple panel instruments.
• Front panel rated to IP 52 provides protection against dust ingress and water spray, suitable for industrial enclosures and switchgear panels.
• High overload tolerance – withstands 40 times rated current for 1 second, protecting the instrument during short-circuit or fault conditions.
• Wide frequency compatibility from 20 to 100 Hz accommodates both standard power frequencies and variable-frequency drive applications.

Applications:

• Current monitoring on industrial switchgear and motor control centre panels.
• Load supervision in AC distribution boards and sub-distribution panels.
• Visual current indication in building electrical installation cubicles.
• AC motor current display in machine control and automation panels.

Also known as: Circutor EC96 20A, EC96 20A M10235, moving iron ammeter 20 A, panel ammeter 96×96, Circutor M10235.
