The Circutor SEC96 100/5 A (code M102XC) is an exchangeable scale face for Circutor EC96 moving iron ammeters. It is designed to display AC current measured via a current transformer with a 100 A primary and 5 A secondary ratio, and fits directly into the 96 x 96 mm EC96 instrument housing. The scale measures 84 x 84 x 1 mm and weighs just 9 g, making it a lightweight, drop-in replacement for worn or damaged ammeter dials.

Technical specifications:

• Model: SEC96 100/5 A
• Circutor code: M102XC
• EAN: 8433059001964
• Measurement range: 100/5 A
• Full scale: 100/5 A
• Compatible instrument: EC96 moving iron ammeter
• Panel module size: 96 x 96 mm
• Scale dimensions: 84 x 84 x 1 mm
• Weight: 0.009 kg

Features and benefits:

• Direct replacement for EC96 instrument faces – restores a legible scale without replacing the entire ammeter
• Calibrated for the 100/5 A CT ratio – displays primary current correctly when paired with a matching current transformer
• Exchangeable format – allows the EC96 ammeter to be re-ranged by fitting a different SEC96 scale if the CT ratio changes
• Slim 1 mm profile and minimal weight (9 g) – straightforward to fit and handle during panel maintenance

Applications:

• Replacing cracked, faded, or illegible scale faces on Circutor EC96 panel ammeters
• Re-ranging existing EC96 instruments when a new 100/5 A current transformer is installed
• Spare parts stock for industrial switchboards, motor control centres, and distribution boards fitted with EC96 ammeters
• Planned maintenance programmes requiring periodic renewal of panel instrument scales

Also known as: Circutor SEC96 100/5 A, SEC96 100/5 A M102XC, Circutor M102XC, EC96 ammeter replacement scale, Circutor moving iron ammeter scale.
