The Circutor SEC96 400/5 A (code M102XJ) is an exchangeable replacement scale for EC96 moving iron ammeters, calibrated for use with 400/5 A current transformers. The 84 84 1 mm dial plate drops into any EC96 instrument housed in a 96 96 mm panel cutout, allowing the displayed measurement range to be updated without replacing the full ammeter.

Technical specifications:

• Model: SEC96 400/5 A
• Circutor code: M102XJ
• EAN: 8433059002138
• Measurement range: 400/5 A
• Full scale: 400/5 A
• Compatible device: EC96 moving iron ammeter
• Module size: 96 96 mm
• Scale dimensions: 84 84 1 mm
• Weight: 0.01 kg

Features and benefits:

• Exchangeable scale design lets engineers change the displayed current range on an existing EC96 ammeter without purchasing a new instrument
• Graduated specifically for 400/5 A CT outputs, giving accurate panel readings when paired with a matched current transformer
• At just 1 mm thick and 0.01 kg, the scale fits flush inside the EC96 housing with no modification to the panel or meter body
• Part of the SEC96 range, which covers scales from 5/5 A up to 5000/5 A, allowing consistent ammeter housings across an entire switchboard

Applications:

• Replacing worn, faded, or damaged scales in installed EC96 moving iron ammeters
• Reconfiguring existing panel instrumentation after a CT ratio change to 400/5 A
• New switchgear and distribution board builds using EC96 ammeters with 400/5 A current transformers
• Industrial and commercial electrical panels where 400 A primary current measurement is required via CT secondary

Also known as: Circutor SEC96 400/5 A, SEC96 400/5 A M102XJ, Circutor M102XJ ammeter scale, EC96 replacement scale, moving iron ammeter exchangeable dial.
