The Circutor SEC96 2000/5A (code M102XS) is an exchangeable scale plate for EC96 series moving iron ammeters. It replaces the dial face on a 96 x 96 mm panel ammeter to display a full-scale reading of 2000/5 A, making it suitable for use with current transformers that have a 5 A secondary output. The scale itself measures 84 x 84 x 1 mm and weighs 0.01 kg.

Technical specifications:

• Model: SEC96 2000/5A
• Circutor code: M102XS
• EAN: 8433059002282
• Measurement range: 2000/5 A
• Full scale: 2000/5 A
• Compatible device: EC96 moving iron ammeter
• Panel format (modules): 96 x 96 mm
• Scale plate dimensions: 84 x 84 x 1 mm
• Weight: 0.01 kg

Features and benefits:

• Exchangeable design lets you swap the dial face without removing or replacing the entire ammeter body
• 2000/5 A range matches installations where current transformers deliver a 5 A secondary signal
• 84 x 84 x 1 mm plate is purpose-made to fit the EC96 96 x 96 mm panel format exactly
• At 0.01 kg the scale adds negligible weight to the panel assembly

Applications:

• Replacing worn or damaged dial faces on Circutor EC96 moving iron ammeters
• Updating a panel ammeter to the 2000/5 A range following a current transformer change
• Industrial switchgear panels and motor control centres fitted with EC96 ammeters
• Electrical distribution boards using 96 x 96 mm panel instrumentation

Also known as: Circutor SEC96 2000/5A, SEC96 2000/5A M102XS, Circutor M102XS scale, EC96 replacement scale, moving iron ammeter dial face.
