The Circutor SEC72 20/5 A (code M102Y5) is an exchangeable replacement scale for the EC72 series moving iron ammeter. Printed for a 20/5 A measurement range, this dial face allows the EC72 instrument to display primary current up to 20 A when paired with a current transformer having a 5 A secondary output. The scale measures 60 x 60 x 1 mm and fits the 72 x 72 mm panel module format of the EC72 ammeter.

Technical specifications:

• Model: SEC72 20/5 A
• Circutor code: M102Y5
• EAN: 8433059002497
• Measurement range: 20/5 A
• Full scale: 20/5 A
• Compatible ammeter: EC72
• Panel module size: 72 x 72 mm
• Scale dimensions: 60 x 60 x 1 mm
• Weight: 0.004 kg

Features and benefits:

• Exchangeable design allows the ammeter display range to be updated without replacing the complete instrument
• Calibrated for 20/5 A CT ratios, providing direct primary current readout up to 20 A on the dial face
• Slim 1 mm profile fits precisely within the EC72 ammeter housing
• Compatible with the EC72 and EMSC series of moving iron ammeters from Circutor
• Lightweight at 4 g, adding negligible load to the panel mounting assembly

Applications:

• Replacing a worn or damaged scale face on an existing EC72 moving iron ammeter
• Re-ranging an EC72 ammeter to match a current transformer with a 20 A primary and 5 A secondary
• Electrical distribution boards requiring a 72 x 72 mm format panel ammeter covering up to 20 A primary
• Industrial control panels where CT-connected ammeters need a specific scale for a 20/5 A measurement range

Also known as: Circutor SEC72 20/5 A, SEC72 20/5A M102Y5, EC72 ammeter replacement scale, Circutor exchangeable ammeter scale, moving iron ammeter dial 20A.
