The Circutor SEC72 600/5A Scale (code M102YL) is an exchangeable dial scale for the EC72 moving iron ammeter, designed for panel installations using a 72 x 72 mm module format. It provides a 600/5 A measurement range, allowing the ammeter to display current readings up to 600 A when the instrument is connected to a 5 A secondary current transformer.

Technical specifications:

• Model: SEC72 600/5A Scale
• Circutor code: M102YL
• EAN: 8433059002909
• Measurement range: 600/5 A
• Full scale: 600/5 A
• Compatible device: EC72 moving iron ammeter
• Panel module size: 72 72 mm
• Scale face dimensions: 60 60 1 mm
• Weight: 0.004 kg

Features and benefits:

• Exchangeable format allows the scale face to be swapped without removing or replacing the entire ammeter unit
• 600/5 A range suits standard 5 A secondary CT circuits measuring primary currents up to 600 A
• Slim 1 mm thickness and 60 60 mm face fit precisely within the EC72 72 72 mm panel cut-out
• Weighs just 0.004 kg, adding negligible load to the instrument panel

Applications:

• Replacing a worn or damaged scale on an existing EC72 moving iron ammeter
• Reconfiguring an EC72 panel instrument to a 600/5 A display range
• Industrial switchboards and distribution panels using 600 A primary / 5 A secondary current transformers
• Control panels and enclosures built around 72 72 mm format instruments

Also known as: Circutor SEC72 600/5A Scale, SEC72 600/5 A M102YL, EC72 ammeter replacement dial, moving iron ammeter scale 600/5A, Circutor M102YL scale.
