The Circutor SEC72 3000/5A Scale (code M102YU) is an exchangeable display scale for EC72 moving iron ammeters. It carries a 3000/5 A full-scale marking, pairing with a 3000/5 A current transformer secondary to indicate primary current up to 3000 A on the panel instrument face. The scale fits the 72 72 mm EC72 ammeter housing and measures 60 60 1 mm.

Technical specifications:

• Model: SEC72 3000/5A Scale
• Circutor code: M102YU
• EAN: 8433059003104
• Measurement range: 3000/5 A
• Full scale: 3000/5 A
• Compatible device: EC72
• Module format: 72 72 mm
• Scale dimensions: 60 60 1 mm
• Weight: 0.004 kg

Features and benefits:

• Exchangeable design allows the scale face to be swapped without replacing the entire ammeter body
• 3000/5 A range covers high-current distribution applications measured via standard 5 A CT secondary
• 72 72 mm module format is a direct match for EC72 panel ammeter housings
• 1 mm thin profile fits the standard EC72 scale recess without modification
• Weighing only 0.004 kg, the scale is easy to handle during installation or servicing

Applications:

• Replacing worn or damaged scale faces in EC72 moving iron ammeters on live panels
• Main distribution boards and switchgear panels measuring primary currents up to 3000 A through a 3000/5 A current transformer
• Industrial control panels where EC72 ammeters are installed and periodic scale replacement is part of planned maintenance
• Spare-parts inventory for facilities operating multiple EC72 ammeter instruments

Also known as: Circutor SEC72 3000/5A Scale, SEC72 3000/5 A M102YU, Circutor M102YU ammeter scale, EC72 replacement scale, exchangeable ammeter scale 3000/5 A.
