The Circutor SEC72 FA 800/5 A (code M105YN) is an exchangeable scale face for use with EC72 FA moving iron ammeters. It provides a calibrated replacement dial for 800/5 A current transformer circuits and is sized to fit 72 x 72 mm panel instruments. The scale measures 60 x 60 x 1 mm and weighs 0.004 kg, making it straightforward to fit or swap on site.

Technical specifications:

• Model: SEC72 FA 800/5 A
• Circutor code: M105YN
• EAN: 8433059004958
• Full scale: 800/5 A
• Compatible device: EC72 FA
• Panel module size: 72 x 72 mm
• Scale dimensions: 60 x 60 x 1 mm
• Weight: 0.004 kg

Features and benefits:

• Exchangeable design lets the scale face be swapped without replacing the entire EC72 FA moving iron ammeter
• Calibrated specifically to the 800/5 A range for accurate current readings from 800 A primary current transformers with 5 A secondary output
• Slim 1 mm profile and compact 60 x 60 mm dimensions allow straightforward fitment into 72 x 72 mm panel cut-outs
• Very low weight of 0.004 kg minimises handling effort during installation or routine maintenance

Applications:

• Replacing worn, damaged, or incorrectly ranged scales on EC72 FA moving iron panel ammeters
• Reconfiguring an existing 72 x 72 mm panel ammeter to display an 800/5 A current transformer circuit
• Maintenance spare for industrial switchgear cabinets and distribution panels fitted with EC72 FA instruments
• Electrical installation projects requiring 800 A current monitoring via 5 A secondary current transformers

Also known as: Circutor SEC72 FA 800/5 A, SEC72 FA 800/5 A M105YN, Circutor M105YN, EC72 FA replacement scale, moving iron ammeter dial 800 A.
