The Circutor SEC72 FA 1200/5A (code M105YQ) is an exchangeable display scale for the EC72 FA moving iron ammeter, calibrated to a full scale of 1200/5 A. Designed for the 72 x 72 mm panel-mount EC72 FA instrument, it allows the displayed current range to be changed without removing or replacing the ammeter movement.

Technical specifications:

• Model: SEC72 FA 1200/5A
• Circutor code: M105YQ
• EAN: 8433059265038
• Full scale: 1200/5 A
• Compatible device: EC72 FA
• Panel module size: 72 x 72 mm
• Scale dimensions: 60 x 60 x 1 mm
• Weight: 0.004 kg

Features and benefits:

• Exchangeable design lets the current range of an EC72 FA ammeter be updated without removing the instrument movement from the panel.
• Full-scale marking of 1200/5 A provides a calibrated readout at the upper range of the instrument.
• Compact at 60 x 60 x 1 mm and 0.004 kg, the scale fits within the 72 x 72 mm EC72 FA housing without adding bulk.
• Part of the wide SEC72 FA range covering full scales from 50/5 A up to 5000/5 A, simplifying sourcing for any EC72 FA ammeter in service.

Applications:

• Replacing worn or damaged display scales on EC72 FA ammeters in industrial switchboards and motor control centres
• Reconfiguring a 72 x 72 mm panel ammeter to display a 1200/5 A measurement range
• Spare-part stocking for distribution board or substation installations using EC72 FA instruments
• Retrofit of panel instruments where the measured current range has been changed to 1200/5 A

Also known as: Circutor SEC72 FA 1200/5A, SEC72 FA 1200/5A M105YQ, EC72 FA replacement scale, 1200/5A ammeter scale, moving iron ammeter scale 72×72.
