Technical Specifications Brand: Radxa SoC: Rockchip RK3568 CPU: Quadcore Arm CortexA55 (Armv8) 64bit @ 2.0GHz GPU: Arm Mali G52 GPU – OpenGL ES 1.1 / 2.0 / 3.2 – OpenCL 2.0 – Vulkan 1.1 NPU: 1 TOPs @ INT8 / INT16 / FP16 / BFP16 MAC hybrid operation Support deep-learning frameworks: TensorFlow, TF-lite, Pytorch, Caffe, ONNX, MXNet, Keras, Darknet Multimedia: H.265 / H.264 / VP9 video decoder up to 4K@60fps H.264 / H.265 video encoder up to 1080@60fps RAM: 2 / 4 GB 32bits LPDDR4 Storage: 1x eMMC connector 1x M.2 M Key (2lane PCIe 3.0) supporting NVMe SSD 1x Micro SD(TF) card slot Display: 1x Standard HDMI 2.0 supporting displays up to 4Kp60 resolution 1x 2lane MIPI DSI supporting displays up to 2Kp60 resolution Camera: 1x 2-lane MIPI CSI for camera Ethernet: 1x Gigabit Ethernet port supports PoE with PoE HAT USB: 1x USB3.0 HOST port 1x USB3.0 OTG/HOST port 2x USB2.0 HOST ports Audio: 1x 4ring 3.5mm Headphone Jack Software: Debian Linux support Android 11 support Power Requirements: – USB TypeC PD V2.0 supporting 9V/2A, 12V/2A, 15V/2A and 20V/2A. – Qualcomm Quick Charge 2.0 QC3.0/2.0 adapter 9V/2A and 12V/1.5A. – 5V Power applied to the GPIO PIN 2 & 4 Operating Conditions: Recommended environmental temperature: 0 ~ 50C Dimension: 85 mm x 56 mm Warranty Information All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.
