The XA2ED33 is a complete 3-position selector switch in Schneider Electric’s Easy Harmony XA2 range, designed for 22 mm panel cutouts. It features a black standard non-spring-return handle with 2 NO contacts switching at 45 positions, rated at 3 A at 240 V AC-15. IP65 protection and 300,000 cycle mechanical durability make it suitable for demanding industrial control panel applications.

Technical specifications:

• Commercial reference: XA2ED33
• Manufacturer: Schneider Electric
• EAN: 3606480673863
• Series / range: Easy Harmony XA2
• Mounting diameter: 22.5 mm
• Number of positions: 3, at 45
• Contact configuration: 2 NO, slow break
• Rated operational current [Ie]: 3 A at 240 V AC-15 / 0.27 A at 250 V DC-13
• Conventional thermal current [Ith]: 10 A
• Rated insulation voltage [Ui]: 600 V (IEC 60947-1)
• Rated impulse withstand voltage [Uimp]: 6 kV (IEC 60947-1)
• Mechanical durability: 300,000 cycles
• Electrical durability: 500,000 cycles AC-15, 3 A at 230 V
• Terminal capacity: 0.5 – 2.5 mm; Faston 6.3 mm
• Dimensions (W x H x D): 30 x 42 x 68.2 mm
• Weight: 0.054 kg
• IP protection: IP65 (IEC 60529)
• IK protection: IK06 (IEC 60529)
• Operating temperature: -25…55 C
• Standards: IEC 60947-5-1, IEC 60947-1, GB 14048.1, GB 14048.5
• Certifications: CE, CCC

Features and benefits:

• Three-position maintained selector ensures reliable mode selection without accidental spring return
• IP65 and IK06 rated – dust-tight, water-jet-resistant, and impact-resistant for industrial environments
• 300,000 mechanical and 500,000 electrical cycles for extended service life
• Flexible wiring: screw terminals accepting 0.5 – 2.5 mm plus 6.3 mm Faston connection option
• Compact 30 x 42 mm footprint for space-efficient control panel layouts

Applications:

• Machine tool control panels for operating mode and direction selection
• Industrial automation and motor control cabinets
• HVAC and building automation control circuits
• Manufacturing equipment and process control panels

Compliant with IEC 60947-5-1 and IEC 60947-1. Part of the Schneider Electric Easy Harmony XA2 range.

Also known as: Schneider XA2ED33, Schneider Electric XA2ED33, Easy Harmony XA2 3-position selector switch 22mm.
