Tecumseh 3ARR3A6TV2 Compressor Start Potential Relay.

Specifications

• Brand: Tecumseh
• Part number: 3ARR3A6TV2
• Continuous Coil Voltage: 420V AC (60 Hz)
• Pick-Up Voltage Range: 209V to 212V AC (Minimum) up to 232V to 235V AC (Maximum)
• Drop-Out Voltage: 121V to 124V AC (Maximum)
• Contact Current Rating: 35 Amps maximum (Break Only)
• Contact Design: Normally Closed (NC)
• Condition: New
• Country of origin: Mexico

Typical applications

Replacement control for HVAC and refrigeration equipment. Match the part number, voltage and ratings of the original before installing, and turn off power before servicing.

Before you order, match the part number or the specs on the nameplate of the part you are replacing. Not sure it fits? Send us the model and serial number of your unit and we will confirm.
